LED-3815/4225/6040 Series

LED-CYLINDER
CYLINDER
This cylinder architectural series is elegant and functional. With different mounting options and CCT selectable, the fixtures provides high flexibility for all environments. The high performance LEDs and long lasting driver also provides effective lighting all around.


Spec. Download
  • CYLINDER

    -UL and CUL listed.

    Housing:
    -Superior heavy duty die cast aluminum extrusion construction.

    Options:
    UV stabilized powder coated finish for outdoor.


    Model Number Nominal Watts**         Lumen**              Efficacy**             Angle
    LED-3815W 13W 1559 lm** 126 lm/w**


    45° / 75°
    *45° is only for exclusive
    for 4225 and 6040 series
    LED-4225W 20W 2542 lm** 130 lm/w**
    LED-6040W 33W 4571 lm** 147 lm/w**
    LED-3815C/P 13W 1670 lm** 125 lm/w**
    LED-4225C/P 20W 2485 lm** 120 lm/w**
    LED-6040C/P 33W 4825 lm** 140 lm/w**
    LED-4225D 20W 2485 lm** 120 lm/w**
    LED-6040D 33W 4825 lm** 140 lm/w**
    ** Lumen and Efficacy are based on highest wattage 5000K at 75° Angle


    Build Your Order
    Model
    Number    		 Nominal
    Watts**    		 Voltage CCT Angle Finish Option
    LED-3815X
    LED-4225X
    LED-6040X
    		 13W
    20W
    33W
    120-277V

    3000K/4000K/5000K

    		 45°
    75°    		 WH = White
    BK = Black
    GY = Gray    		 R = 4ft (4x12") connectable
    stems and base for
    pendant mount
    **Optional with adder
    **Disclaimer: This test report was produced in accordance with IES LM-79 photometric testing protocol for luminaires, using a single representative test fixture.
       Actual production units may vary from the values reported here by up to +/-10%.

  •  Download Datasheet
