LED-3110

LED-3110
LED SURFACE MOUNT LIGHT

The LED-3110 is a powerful luminaire that has been designed to meet a wide variety of locations. With the varioius mounting options, it can be used as a flood light or as an area light.
With the LEDs mounted on the large heatsink, the fixture can maintain a high lumen output while keeping the LED modules at a cool temperature.
Spec. Download
  • LED SURFACE MOUNT LIGHT

    -UL and CUL listed for wet location.
    -Heavy duty die-cast aluminum powder coating, corrosion resistant hardware.
    -​UV stabilized powder coated finish.
    -Heat and impact PC lens.
    -Finish: Bronze. Color option with adder.

    Options:
    -Narrow/ Wide distribution available with adder.


    Model Number LED-3110
    System Wattage 20/30/40W 25/45/55W
    Delivered Lumens (Lms.) 5594 lm** 7237 lm**
    Efficacy (Lm/W) 140 lm/w 132 lm/w
    Color Rendering Index (CRI) 70+
    Color Temperature (CCT) 4000K/ 5000K
    Input Voltage 120~277V
    Dimensions (Inches) 14.2" x 9.55" x 5.15" inches

    Build Your Order
    Model
    Number    		 System
    Wattage    		 Distribution Voltage CCT Optional accessoy Housing
    Finish    		 Starting temperature

    LED-3110
         		 20/30/40W
    25/45/55W    		 TYPE III
    TYPE IV    		 120-277V 4000K
    5000K
    CUSTOM**    		 Photo control**
    Emergency driver    		 Bronze
    CUSTOM**    		 -40ﾟC
    **Optional with adder
      *Different LED Kelvin temperature available with 5-6 week lead time. Please call for quote.
    **Disclaimer: This test report was produced in accordance with IES LM-79 photometric testing protocol for luminaires, using a single representative test fixture.
       Actual production units may vary from the values reported here by up to +/-10%.

  •  Download Datasheet
