LED-368

LED-368
LED CANOPY LIGHT

Heavy-duty die-cast construction with modular LED light engine design.
This slim-profile luminaire can be perfectly used in gas station, parking garage, canopy or high ceilings.
It provides an easy installation with quick mount structure for contractors to work safely and easily in the confined-space areas.


Spec. Download
  • LED CANOPY LIGHT

    -UL and CUL listed for damp locations.
    -Solid construction die cast aluminum body.
    -UV stabilized powder coated finish.
    -Heat and impact resistant tempered glass.
    -DLC Listed.
    -Patented Fixture.
    -Finish:  White. Color option with adder.
    -Quick Mount.


    Model Number LED-368-L4 LED-368-L192
    System Wattage 99W 130W 186W 165W
    Delivered Lumens (Lms.) 12560 15362 19246 21120
    Efficacy (Lm/W) 127 lm/w 118 lm/w 103 lm/w 128 lm/w
    MA 625 800 800 130
    Equivalent 250W MH 250W MH 400W MH 400W MH
    Color Rendering Index (CRI) 70+
    Color Temperature (CCT) 5000K
    Input Voltage 120~277V
    Dimensions (Inches) 16.53" x 16.53" x 10.86"
    Weight (kg / lb) 9.49 kg / 20.92lb


    Build Your Order
    Model
    Number    		 System
    Wattage    		 Voltage Electrical CCT Housing
    Finish    		 Mounting
    LED-368-L4
    LED-368-L192    		 99W
    130W
    186W
    165W    		 120-277V N/A 5000K
    CUSTOM**    		 White
    CUSTOM**    		 Surface Mount
    **Optional with adder
      *Different LED Kelvin temperature available with 5-6 week lead time. Please call for quote.
    **Disclaimer: This test report was produced in accordance with IES LM-79 photometric testing protocol for luminaires, using a single representative test fixture.
       Actual production units may vary from the values reported here by up to +/-10%.
