SML-009/SML-012

SML-009/012
LED CANOPY LIGHT

This rugged-designed LED canopy fixture will outlast the competition.
With light output of a typical 70W-150W metal halide it is an energy efficient replacment .
Two sizes available allow these fixtures to be used in a wide variety of locations.


Spec. Download
  • LED CANOPY LIGHT

    -UL and CUL listed for wet locations.
    -Solid construction die cast aluminum body.
    -UV stabilized powder coated finish.
    -High impact acrylic diffuser.
    -DLC Listed.
    -Optional Photo Control with adder.
    -Optional 347V with adder.
    -Finish:  Bronze. Color option with adder.


    Model Number SML-009 SML-012
    System Wattage 20 38 55
    Delivered Lumens (Lms.) 2014  3605 3906
    Efficacy (Lm/W) 101 95 72
    Dimensions (Inches) 8.9"x 8.9" x 7.1"  12.4"x 12.4" x 8.9"
    Color Rendering Index (CRI) 70+
    Color Temperature (CCT) 5000K
    Input Voltage 120~277V
    MA 480 MA 950 MA 1400 MA
    Equivalent 70W-100W MH 100W MH 150W MH
    Weight (kg / lb) 3.92kg / 8.64lb


    Build Your Order
    Model
    Number    		 System
    Wattage    		 Distribution Voltage CCT Electrical Housing
    Finish    		 Mounting
    SML-009
    SML-012    		 20W
    38W
    55W    		 N/A 120-277V
    347V**    		 5000K
    CUSTOM**    		 Photo control** Bronze
    CUSTOM**    		 Surface Mount
    **Optional with adder
      *Different LED Kelvin temperature available with 5-6 week lead time. Please call for quote.
    **Disclaimer: This test report was produced in accordance with IES LM-79 photometric testing protocol for luminaires, using a single representative test fixture.
       Actual production units may vary from the values reported here by up to +/-10%.

  •   Download Datasheet
