Download Datasheet
Model Number |
LED-8320-L192 |
LED-8320-L256 |
LED-8320-L384 |
System Wattage |
244W |
305W |
492W |
Dist. Type |
Type III |
Type V |
Type III |
Type V |
Type III |
Type V |
Delivered Lumens (Lms.) |
24468 lm** |
24973 lm** |
32230 lm** |
31892 lm** |
49144 lm** |
52693 lm** |
Efficacy (Lm/W) |
100 lm/W |
102 lm/W |
132 lm/W |
104 lm/W |
161 lm/W |
173 lm/W |
Color Rendering Index (CRI) |
70+ |
Color Temperature (CCT) |
3000K / 4000K / 5000K |
Input Voltage |
120~277V AC |
Dimensions (Inches) |
25.2" x 5.6" x 15.7" inches |
|
Build Your Order
Model
Number |
System
Wattage |
Voltage |
CCT |
Electrical |
Housing
Finish |
Mounting |
LED-8320 |
244W
305W
492W |
120-277V
347V** |
3000K
4000K
5000K
CUSTOM** |
Dimmable**
|
Bronze
CUSTOM** |
Trunnion
Slip Fitter
Pole Mount |
**Optional with adder
*Different LED Kelvin temperature available with 5-6 week lead time. Please call for quote.
**Disclaimer: This test report was produced in accordance with IES LM-79 photometric testing protocol for luminaires, using a single representative test fixture.
Actual production units may vary from the values reported here by up to +/-10%.
